PISTON KIT 89-95 RM250 69.00, WOSSNER 8022D200 SUZUKI MX
Wossner 8022D200 Piston Kit with a 69mm bore (68.94mm actual size) is forged in Germany for high durability and strength. It is designed to maximise heat transfer from the combustion chamber to the cylinder walls. The elliptical piston shape promotes even distribution of thrust loads under heat expansion, reducing localised stresses and preventing piston collapse. Features include forged construction for enhanced strength and resilience, optimised for efficient heat transfer to cylinder walls, elliptical design for uniform load distribution under thermal expansion, and manufactured in Germany. Specifications include Bore: 69mm (actual size 68.94mm), Part Number: 56-W642_200.WO, Lock Part Number: CW18, Pin Part Number: WP033, Ring Set Part Number: RSB6700 x 2, Displacement: 246 cm³, Stroke: 70.80mm, Clearance: 0.06mm, Wossner Compression Ratio: 2-stroke, OEM Compression Ratio: 2-stroke, and Compression Height: 37.00mm. Cross-reference OEM Part Numbers include Piston: 12110-28C11-0F0, 12110-29E20-0F0; Ring, Piston: 12141-41600, 12141-41620; Pin, Piston: 12151-28C00, 12151-37F00; and Circlip: 09381-18002.
- SKU
- 56-W642_200.W0
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Piston Kit - 69mm Bore
This Wossner piston kit is engineered for high performance and durability, featuring a 69mm bore (68.94mm actual size). Manufactured in Germany, this piston is designed to maximize heat transfer from the combustion chamber to the cylinder walls. Its innovative elliptical shape ensures an even distribution of thrust loads, even under extreme heat expansion. This design reduces localized stresses and helps prevent piston collapse, ensuring longevity and optimal engine performance.
Key Features:
- Forged construction for superior strength and resilience.
- Optimized for efficient heat transfer, promoting cooler engine operation.
- Elliptical piston design for uniform load distribution and reduced stress.
- Precision manufactured in Germany for quality you can trust.
Specifications:
- Bore Size: 69mm (actual 68.94mm)
- Piston Pin Part Number: WP033
- Lock Ring Part Number: CW18
- Ring Set Part Number: RSB6700 x 2
- Stroke: 70.80mm
- Clearance: 0.06mm
- Compression Height: 37.00mm
