PISTON KIT 93-95 KLX650 102.00, FORGED WOSSNER 8512D200
Wossner forged piston kit with a 102mm bore, 2.00mm oversize. Engineered for optimal combustion chamber heat transfer and uniform bearing surface under heat expansion, reducing localized pressure and piston collapse. Manufactured in Germany for durability and precision. Features forged piston for superior strength and design, optimized heat transfer to cylinder walls, elliptical design for uniform bearing surface and even thrust load distribution. Specifications include a 102mm bore, standard size piston (PN# 8512D200), lock part number CW24, pin part number WP057, ring set part number 1020XSU, displacement 651 cm³, stroke 83.00mm, clearance 0.06mm, Wossner compression ratio OEM, OEM compression ratio 9.50:1, dome volume -24.90 cm³, and compression height 29.50mm.
- SKU
- 56-W173+2.00
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 102mm Oversize
Upgrade your engine's performance and durability with this premium Wossner forged piston kit. Engineered for precision and strength, this kit features a 102mm bore, providing a 2.00mm oversize replacement for optimal performance. The advanced forged construction ensures superior resistance to heat and stress, making it an ideal choice for demanding applications.
This piston kit is designed with an elliptical profile to guarantee a uniform bearing surface, even under extreme heat expansion. This intelligent design prevents localized pressure points and reduces the risk of piston collapse, ensuring consistent performance and extended engine life. Manufactured in Germany, each component meets the highest standards of quality and reliability.
Key Features:
- Forged Piston Construction: Offers exceptional strength and durability compared to cast pistons.
- Optimized Heat Transfer: Promotes efficient heat dissipation to the cylinder walls, reducing operating temperatures.
- Elliptical Design: Ensures even bearing surface and thrust load distribution for reduced wear.
- Precision Manufacturing: Made in Germany to exacting standards for a perfect fit and reliable operation.
- Oversize Bore: 102mm bore (+2.00mm oversize) for enhanced engine performance.
Specifications:
- Bore Size: 102mm
- Oversize: +2.00mm
- Standard Size Piston Part Number: 8512D200
- Lock Part Number: CW24
- Pin Part Number: WP057
- Ring Set Part Number: 1020XSU
- Engine Displacement: 651 cm³
- Stroke Length: 83.00mm
- Piston Clearance: 0.06mm
- Compression Ratio (Wossner): OEM
- Compression Ratio (OEM): 9.50:1
- Dome Volume: -24.90 cm³
- Compression Height: 29.50mm
