SPRING VALVE EXHAUST RMZ450, XU-09527ES
21,45 €
1
Qty
1
SPRING VALVE EXHAUST PSYCHIC XU-09527ES. Springs are made of SWOSC-V material oil tempered steel wire. Some springs feature a progressive style design. Progressive style springs have more coils on one end. The end with more coils is heavier and should always be installed towards the bottom. Non-progressive springs are paint marked on the end that is to be installed towards the top. Cross reference numbers 12921-28H00. DIMENSIONS WIRE DIA 3.0MM, O.D.23/I.D.17MM (+/-0.2), LENGTH 34.5MM (+/- 0.5), 6 ROLL.
Specifications
- SKU
- 65-6378.PS
- Brand
- Dirt Racing
- Availability
- In Stock (30)
General Product Group
Cam & Valvetrain
General Product Type
Valve Spring
Variant Id
264322
Shipping OptionsShown at checkout
14-Day ReturnsHassle-free
Easy CheckoutCard friendly
Product details
FULL DESCRIPTION
Exhaust Valve Spring for Suzuki Motorcycles
This is a high-quality exhaust valve spring designed for specific Suzuki motorcycle models. It is engineered to meet the demands of performance and durability, ensuring optimal engine function.
Key Features:
- Material: Constructed from SWOSC-V oil tempered steel wire for superior strength and resilience.
- Design: Some springs feature a progressive style design with more coils on one end. The heavier end with more coils should always be installed towards the bottom of the valve assembly.
- Identification: Non-progressive springs are paint marked on the end intended for installation towards the top.
- Dimensions:
- Wire Diameter: 3.0mm
- Outer Diameter (O.D.): 23mm (+/- 0.2mm)
- Inner Diameter (I.D.): 17mm (+/- 0.2mm)
- Length: 34.5mm (+/- 0.5mm)
- Number of Coils: 6
- Manufacturer: Dirt Racing
