PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV
Wossner forged piston kit 67.50mm bore, +0.50mm oversize (actual 67.44mm) for 1987 Suzuki LT250 ATV. Designed for 2-stroke engines with forged construction for strength and thermal management. Features an elliptical piston shape for even thrust load distribution. Made in Germany. Specifications: Bore Size 67.50mm, Compression Height 37.20mm, Clearance 0.06mm, Stroke 70.00mm, Displacement 246 cm³. Includes Wossner Piston 8258D050, Ring Set RSB6750 (x2), Lock CW18, Pin WP033.
- SKU
- 56-W577+0.50.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 67.50mm Bore
This Wossner forged piston kit is designed for enhanced performance in 2-stroke engines. It features a +0.50mm oversize bore with an actual bore size of 67.44mm. The forged construction provides superior strength and excellent thermal management capabilities. An elliptical piston shape ensures even thrust load distribution, which helps reduce stress and the risk of failure during high thermal expansion. This piston kit is precision manufactured in Germany.
Key Features
- Forged piston design for increased strength and longevity.
- Engineered for efficient heat dissipation from the combustion chamber.
- Elliptical profile ensures uniform bearing surface under heat expansion.
- Developed specifically for 2-stroke engine use.
- Manufactured in Germany for quality assurance.
Specifications
- Bore Size: 67.50mm (+0.50 oversize)
- Actual Bore: 67.44mm
- Compression Height: 37.20mm
- Clearance: 0.06mm
- Stroke: 70.00mm
- Displacement: 246 cm³
- Wossner Compression Ratio: 2-stroke
- OEM Compression Ratio: 2-stroke
Included Components
- Wossner Piston: 8258D050
- Ring Set: RSB6750 (x2)
- Lock: CW18
- Pin: WP033
