PISTON KIT 92-13 TM 125 54.00, WOSSNER 8135DB FORGED
Wossner forged piston kit for 2-stroke engines. Engineered for superior strength and performance with optimal heat transfer. Features an elliptical design for uniform bearing surface under heat expansion, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany. Bore: 53.95 mm, Piston Size: 54.01 mm, Displacement: 123 cm³, Stroke: 54.50 mm, Clearance: 0.06 mm. Cross-reference OEM part numbers include Lock: CW15, Pin: WP032, Ring Set: RSB5400.
- SKU
- 56-W016.B.WO
- Brand
- Wossner
- Availability
- In Stock (2)
FULL DESCRIPTION
Wossner Forged Piston Kit for 2-Stroke Engines
Experience enhanced strength and superior performance with this Wossner forged piston kit. Meticulously engineered in Germany, this piston is designed for optimal heat transfer from the combustion chamber directly to the cylinder walls. Its innovative elliptical design ensures uniform bearing surface even under heat expansion, effectively reducing localized pressure and distributing thrust loads evenly. This advanced design prevents piston collapse and guarantees reliable operation.
Key Features:
- Forged Construction: Provides exceptional durability and strength for demanding use.
- Optimized Heat Transfer: Improves engine performance and longevity by efficiently managing combustion temperatures.
- Elliptical Design: Prevents localized pressure buildup and eliminates the risk of piston collapse.
- Designed for 2-Stroke Engines: Engineered specifically for the demands of 2-stroke powerplants.
Specifications:
- Bore: 53.95 mm
- Piston Size: 54.01 mm
- Displacement: 123 cm³
- Stroke: 54.50 mm
- Clearance: 0.06 mm
- Compression Height: 29.00 mm
Included Components (Cross-Reference):
- Lock: CW15
- Pin: WP032
- Ring Set: RSB5400
