PISTON KIT LTR450 HC 95.50 A, WOSSNER 8699DA 13.3:1 COMP, SUZUKI
Wossner 8699DA forged piston kit for Suzuki LTR450 models. This is a high-compression piston with a 95.50mm bore and a 13.3:1 compression ratio. It is designed for optimized heat transfer and features an elliptical profile to ensure uniform pressure distribution, reducing localized stress and the risk of piston collapse. Manufactured in Germany. Specifications include a bore of 95.50 mm, actual bore diameter of 95.45 mm, display of 450 cm³, hub stroke of 62.80 mm, clearance of 0.05 mm, compression height of 24.50 mm, dome volume of +2.30 cm³, and an OEM compression ratio of 11.70:1. Cross-reference OEM part numbers: Piston 8699DA, Lock CW19, Pin WP037, Ring Set 955XSY, Rod P4011. Part number 56-W4912.WO.A.
- SKU
- 56-W4912.WO.A
- Brand
- Wossner
- Availability
- In Stock (3)
FULL DESCRIPTION
Wossner Forged High Compression Piston Kit for Suzuki LTR450
Enhance your Suzuki LTR450's performance with this Wossner 8699DA forged piston kit. Engineered for high compression and superior durability, this piston is designed to deliver increased power and reliability.
Key Features:
- Forged high-compression piston for increased strength and power output.
- Optimized heat transfer properties manage combustion chamber temperatures effectively.
- Elliptical piston profile ensures uniform pressure distribution, minimizing stress.
- Reduces the risk of localized pressure points and piston collapse under extreme conditions.
- Precision manufactured in Germany for exceptional quality.
Specifications:
- Bore Diameter: 95.50 mm
- Actual Bore Diameter: 95.45 mm
- Engine Displacement: 450 cm³
- Stroke: 62.80 mm
- Piston Clearance: 0.05 mm
- Compression Height: 24.50 mm
- Dome Volume: +2.30 cm³
- Wossner Compression Ratio: 13.30:1
- OEM Compression Ratio Comparison: 11.70:1
