VOLTAGE REGULATOR BETA DAELIM HONDA KYM SYM PIAGIO MALAGUTI
VOLTAGE REGULATOR. Cross Reference Numbers: 31600-SZ1-900 (Daelim), 31600-KAM1-009 (Kymco), 31600-KR3-671, 31600-KR3-670, 31600-KR3-690, 31600-KAS-901, 31600-KS4-841, 31600-KM1-008 (Honda), 2601800 (Malaguti), 495186 (Piaggio), 31600-M56-000 (Sym), 31600-SZ1-900, 31600-KS4-841, 31600-KM1-008, 31600-KR3-670, 31600-KR3-671, 31600-KR3-690, 31600-KS4-770, 31600-KAM1-009, 02601800, 495186, SH535A-12, 31600-M56-000, 10-026. Specifications: Voltage: 12V, Current: 25A, Input Type: Three-Phase (TRIFASICO), Technology: Silicon Controlled Rectifier (SCR), Output Type: Direct Current (DC), With Sensor: Yes. Dimensions: Height: 28mm, Width: 70mm, Length: 80mm, Pitch: 60mm.
- SKU
- 44-0340.RK
- Brand
- No Brand
- Availability
- In Stock (1)
FULL DESCRIPTION
Voltage Regulator for Motorcycles and Scooters
This voltage regulator is designed to manage the electrical output of your vehicle's charging system, ensuring a stable 12-volt supply. It converts the three-phase AC output from the stator into a direct current (DC) needed to power your vehicle's electronics and charge the battery. Featuring a Silicon Controlled Rectifier (SCR) technology, this unit is built for reliability and performance.
Key Features:
- Voltage Output: 12V
- Current Rating: 25A
- Input Type: Three-Phase (TRIFASICO)
- Technology: Silicon Controlled Rectifier (SCR)
- Output Type: Direct Current (DC)
- Sensor Equipped: Yes
Physical Dimensions:
- Height: 28mm
- Width: 70mm
- Length: 80mm
- Mounting Pitch: 60mm
Cross Reference Numbers:
- 31600-SZ1-900 (Daelim)
- 31600-KAM1-009 (Kymco)
- 31600-KR3-671
- 31600-KR3-670
- 31600-KR3-690
- 31600-KAS-901
- 31600-KS4-841
- 31600-KM1-008 (Honda)
- 2601800 (Malaguti)
- 495186 (Piaggio)
- 31600-M56-000 (Sym)
- SH535A-12
- 10-026
