PISTON 86-02 MAICO 250 69.00, FORGED WOSSNER 8045D200 KIT
Wossner 69.00mm (68.93mm) forged piston kit. Bore size 69.00mm, oversize +2.00mm, displacement 245cc, stroke 70.00mm, clearance 0.07mm, compression ratio 2-stroke, compression height 35.70mm. Lock part number CW18, pin part number WP033, ring set part number RSB6900. Designed for strength and precision, this piston ensures efficient heat transfer to the cylinder walls, providing uniform expansion and reducing localized pressure. The elliptical design distributes thrust loads evenly, preventing piston collapse. Manufactured in Germany.
- SKU
- 56-W141+2.00
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit - 69.00mm Bore
Upgrade your Maico MC 250 with this high-performance Wossner forged piston kit. Engineered for strength, precision, and optimal combustion, this piston is designed to deliver superior performance and durability for your motorcycle engine.
Key Features:
- Superior Strength: Manufactured using a forged process for exceptional durability and resistance to high temperatures and pressures.
- Optimized Heat Transfer: Designed to efficiently transfer heat to the cylinder walls, promoting uniform expansion and reducing localized stress for consistent performance.
- Elliptical Design: Features an elliptical piston skirt for even distribution of thrust loads, preventing piston collapse and ensuring a stable bearing surface.
- Precision Engineering: Meticulously crafted to prevent piston collapse under demanding operating conditions.
- German Quality: Proudly made in Germany, adhering to rigorous quality standards for reliable and long-lasting performance.
Specifications:
- Bore Size: 69.00mm (Actual 68.93mm)
- Oversize: +2.00mm
- Displacement: 245cc
- Stroke: 70.00mm
- Clearance: 0.07mm
- Compression Ratio: 2-stroke
- Compression Height: 35.70mm
- Lock Part Number: CW18
- Pin Part Number: WP033
- Ring Set Part Number: RSB6900
