PISTON KIT 00-02 YZF426 95.00, FORGED WOSSNER 8525DC
Wossner forged piston kit with a 95.02mm bore and 94.98mm actual size. This piston kit features forged construction for enhanced strength and durability, optimized heat transfer for improved performance, and an elliptical design for uniform bearing surface distribution. It is designed to match OEM compression ratios. Specifications include a 426cc displacement, 60.10mm stroke, 0.04mm piston clearance, 12.50:1 compression ratio, -7.00cm³ dome volume, and 24.10mm compression height. Piston lock part number is CW19, piston pin part number is WP037, and ring set part number is 950XDS. Wossner part number 8525DC. Manufactured in Germany.
- SKU
- 56-W4693+00C.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 95.02mm Bore
This Wossner forged piston kit is engineered for superior performance and durability. Featuring a 95.02mm bore and 94.98mm actual size, this piston is designed to meet the demands of high-performance engines.
Key Features:
- Forged Construction: Provides enhanced strength and longevity compared to cast pistons.
- Optimized Heat Transfer: Promotes efficient cooling for improved engine reliability.
- Elliptical Design: Ensures uniform bearing surface distribution, reducing localized pressure and preventing piston skirt collapse.
- OEM Compression Ratio: Designed to match original equipment specifications for seamless integration.
Specifications:
- Bore Size: 95.02mm
- Actual Size: 94.98mm
- Displacement: 426cc
- Stroke: 60.10mm
- Piston Clearance: 0.04mm
- Compression Ratio: OEM (12.50:1)
- Dome Volume: -7.00cm³
- Compression Height: 24.10mm
- Piston Lock Part Number: CW19
- Piston Pin Part Number: WP037
- Ring Set Part Number: 950XDS
Manufacturer Part Number: 8525DC
