PISTON KIT 03-09 CRF230F 67.50, FORGED WOSSNER 8774D200
Wossner 67.50mm forged piston kit offers enhanced strength and durability with engineered optimal heat transfer for efficient combustion chamber cooling. Its elliptical design provides a uniform bearing surface, reducing localized pressure and evenly distributing thrust loads to prevent piston collapse. Manufactured in Germany for precision and reliability. Features include forged construction for enhanced strength and longevity, optimized heat transfer for improved engine performance, and an elliptical design that prevents piston collapse and ensures even load distribution. Specifications: Bore Size 67.50mm, Actual Bore Diameter 67.46mm, Displacement 230 cm³, Stroke 66.20mm, Clearance 0.04mm, Wossner Compression Ratio 11.00:1, OEM Compression Ratio 9.00:1, Dome Volume +3.10 cm³, Compression Height 21.20mm. Gasket Part Number D4002, Lock Part Number CW15, Pin Part Number WP011, Ring Set Part Number 675XKS, Rod Part Number P4053. Wossner Part Number 8774D200.
- SKU
- 56-W4816+200.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 67.50mm
Experience enhanced strength and durability with this Wossner 67.50mm forged piston kit. Engineered for optimal heat transfer, this piston ensures efficient cooling of the combustion chamber, contributing to improved engine performance. The innovative elliptical design provides a uniform bearing surface, effectively reducing localized pressure and distributing thrust loads evenly. This design prevents piston collapse and ensures longevity.
Key Features:
- Forged construction for superior strength and extended lifespan.
- Optimized heat transfer for enhanced engine efficiency.
- Elliptical design promotes even load distribution and prevents piston collapse.
- Precision manufactured in Germany to exacting quality standards.
Specifications:
- Bore Size: 67.50mm
- Actual Bore Diameter: 67.46mm
- Displacement: 230 cm³
- Stroke: 66.20mm
- Clearance: 0.04mm
- Wossner Compression Ratio: 11.00:1
- Dome Volume: +3.10 cm³
- Compression Height: 21.20mm
