PISTON KIT 08-12 RMZ450 96mm, WOSSNER 8716DB SUZUKI FORGED
Wossner 8716DB forged piston kit for 96.01mm bore. Includes lock P/N CW19, pin P/N WP037, ring set P/N 960ADS-2, main bearing P/N 1 x MB83C072C (Right), 1 x MB830053-4 (Left). Display 449 cm3, hub stroke 62.10mm, clearance 0.04mm. Wossner compression ratio OEM, OEM compression ratio 12.20:1, dome volume -0.80 cm3, compression height 23.10mm. Theoretical weight 408 grams. Wossner forged pistons are superior in strength and design, engineered for optimal combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads evenly. Made in Germany.
- SKU
- 56-W4953.B.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 96mm
Upgrade your engine with this high-performance Wossner forged piston kit. Engineered for superior strength and durability, this piston is designed to optimize combustion chamber heat transfer to cylinder walls, ensuring efficient engine operation.
The elliptical design of the piston provides a more uniform bearing surface under heat expansion. This advanced design eliminates localized pressure and distributes thrust loads more evenly, effectively preventing piston collapse and extending engine life.
Key Features:
- Wossner forged pistons offer exceptional strength and advanced design.
- Optimized for efficient combustion chamber heat transfer.
- Elliptical design ensures uniform bearing surface and even thrust load distribution.
- Prevents piston collapse for enhanced engine longevity.
- Manufactured in Germany to exacting standards.
- Piston Bore: 95.97mm
- Nominal Piston Size: 96.01mm
- Included Lock P/N: CW19
- Included Pin P/N: WP037
- Included Ring Set P/N: 960ADS-2
- Compression Height: 23.10mm
- Dome Volume: -0.80 cm3
- Wossner Compression Ratio: OEM
- OEM Compression Ratio: 12.20:1
