PISTON KIT 12-13 KTM EXC500 95, WOSSNER 8821DA HUSQVARNA 78730007000, 79630007000,76630007000

Wossner Forged Piston Kit 95mm Standard Bore

Enhance the performance and durability of your four-stroke motorcycle engine with this high-quality Wossner forged piston kit. Engineered for demanding applications, this standard-size piston is designed for optimal thermal management and structural integrity.

Key Features

• High-Strength Forged Construction: Crafted for maximum durability and resistance to extreme operating conditions.
• Elliptical Piston Profile: Ensures a consistent bearing surface even with thermal expansion, maintaining reliable performance.
• Efficient Heat Dissipation: Designed to effectively transfer combustion heat to the cylinder walls, contributing to engine longevity.
• Even Thrust Load Distribution: Prevents piston collapse and ensures even wear by distributing thrust loads across the piston surface.
• German Manufacturing: Precision engineered and manufactured in Germany for superior quality and reliability.

Specifications

• Bore Size: 95.00mm
• Actual Piston Size: 94.95mm
• Displacement: 510 cm³
• Stroke: 72.00mm
• Piston Clearance: 0.05mm
• Wossner Compression Ratio: OEM
• OEM Compression Ratio: 11.80:1
• Dome Volume: -6.80 cm³
• Compression Height: 22.80mm
• Circlip Part Number: CW19
• Pin Part Number: WP071
• Ring Set Part Number: 950ADS-2

Cross-Reference OEM Part Numbers

• 79630007000
• 78730007000
• 40064M09500
• 76630007000
• 40131M09500
