PISTON KIT 1987 RM125 56.00, WOSSNER 8122D200 SUZUKI MX
Wossner 56.00mm (+2.00 oversize) forged piston kit for two-stroke performance. Features a forged body and elliptical design to enhance heat transfer efficiency and provide uniform load distribution. The thrust load is evenly distributed to reduce localised stress and prevent piston collapse. Engineered for efficient combustion heat transfer to the cylinder walls. Manufactured in Germany. Bore: 56.00mm. Actual diameter: 55.94mm. Displacement: 123 cm³. Stroke: 70.00mm. Clearance: 0.06mm. Compression height: 37.00mm. Compression ratio: 2-stroke. Cross-reference OEM Part Numbers: Piston Kit Part No. 56-W557+200.WO, Wossner Piston Kit No. 8122D200, Lock CW14, Pin WP025, Ring Set RSB5600 x 2.
- SKU
- 56-W557+200_WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner 56.00mm Forged Piston Kit
This Wossner 56.00mm (+2.00 oversize) forged piston kit is engineered for high-performance two-stroke engines. Designed for optimal heat transfer and uniform load distribution, this piston ensures reliability under demanding operating conditions. Manufactured in Germany, it meets stringent quality standards for durability and performance.
Key Features
- Forged Piston: Provides superior strength and durability for high-performance applications.
- Elliptical Design: Maintains a consistent bearing surface by accounting for heat expansion, reducing wear.
- Even Thrust Load Distribution: Minimizes localized stress and prevents piston collapse by distributing forces uniformly.
- Efficient Heat Transfer: Engineered to efficiently transfer combustion heat to the cylinder walls, aiding in engine cooling.
- German Manufacturing: Ensures high quality and reliability.
Specifications
- Bore Size: 56.00mm
- Actual Diameter: 55.94mm
- Displacement: 123 cm³
- Stroke: 70.00mm
- Clearance: 0.06mm
- Compression Height: 37.00mm
- Compression Ratio: 2-stroke
Included Components
- Piston Kit Part Number: 56-W557+
- Wossner Piston Kit Number: 8122D200
- Lock Ring: CW14
- Piston Pin: WP025
- Ring Set: RSB5600 (x2)
