PISTON KIT 82-85 KX125 56.50, WOSSNER 8210D050 FORGED KIT
Wossner 8210D050 forged piston kit with a 56.50mm bore size. Precision-engineered for efficient combustion chamber heat transfer and even thrust load distribution, this German-made piston is elliptically shaped to reduce localized pressure and prevent piston collapse. Features include increased strength and durability, improved heat transfer from the combustion chamber to cylinder walls, and an elliptical design for a uniform bearing surface under heat expansion. Specifications: Bore 56.50 mm, Display 125 cm³, Hub Stroke 50.60 mm, Clearance 0.06 mm, Compression Height 29.70 mm, Compression Ratio 2-stroke (Wossner and OEM). Cross-reference OEM Part Numbers: Piston 8210D050, Lock CW16, Pin WP036, Ring Set RSB5650 x 2, Rod P2037. Part No. 56-W486.050.WO. Manufactured in Germany.
- SKU
- 56-W486.050.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner 8210D050 Forged Piston Kit
Experience enhanced performance and durability with the Wossner 8210D050 Forged Piston Kit. Precision-engineered in Germany, this piston kit is designed to optimize combustion efficiency and withstand demanding riding conditions. Its advanced elliptical shape and forged construction contribute to superior heat transfer and uniform load distribution, preventing premature wear and ensuring reliable operation.
Key Features:
- Forged piston construction for superior strength and longevity.
- Optimized for efficient heat transfer from the combustion chamber to the cylinder walls.
- Elliptical design ensures a consistent bearing surface, even under extreme heat expansion.
- Engineered to prevent localized pressure points and piston collapse.
- Manufactured to high standards in Germany.
Specifications:
- Bore Size: 56.50 mm
- Clearance: 0.06 mm
- Compression Height: 29.70 mm
- Compression Ratio: 2-stroke (compatible with Wossner and OEM specifications)
