PISTON KIT 85-00 XR600R 99.00, FORGED WOSSNER 8574D200
Wossner 99mm forged piston kit. Designed for optimal combustion chamber heat transfer and uniform load distribution, reducing localized pressure and preventing piston collapse. Made in Germany for durability and performance. Features forged construction for superior strength and durability. Optimized heat transfer to cylinder walls. Elliptical design ensures uniform bearing surface under heat expansion. Reduces localized pressure and evenly distributes thrust loads. Prevents piston collapse under high-stress conditions. Specifications include bore size: 99.00mm (actual size: 98.94mm), Wossner part number: 8574D200, lock part number: CW24, pin part number: WP023, ring set part number: 990XSY, rod part number: P4028, displacement: 654 cm³, stroke: 80.00mm, clearance: 0.06mm, compression ratio: 9.30:1, OEM compression ratio: 9.00:1, dome volume: -4.80 cm³, compression height: 29.70mm, and theoretical weight: 348.00g.
- SKU
- 56-W4577.P8.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit for Honda XR600R
This Wossner forged piston kit is precision engineered for enhanced performance and durability in Honda XR600R models. Crafted in Germany, this kit is designed to optimize combustion chamber heat transfer and ensure uniform load distribution, which helps to reduce localized pressure and prevent piston collapse under demanding conditions.
Key Features:
- Forged construction provides superior strength and longevity.
- Designed for optimized heat transfer to cylinder walls for better thermal management.
- Features an elliptical design to maintain a uniform bearing surface during heat expansion.
- Effectively reduces localized pressure and evenly distributes thrust loads for smoother operation.
- Helps to prevent piston collapse in high-stress environments.
Specifications:
- Bore Size: 99.00mm (Actual Size: 98.94mm)
- Displacement: 654 cm³
- Stroke: 80.00mm
- Piston Clearance: 0.06mm
- Compression Ratio: 9.30:1
- OEM Compression Ratio: 9.00:1
- Dome Volume: -4.80 cm³
- Compression Height: 29.70mm
- Theoretical Weight: 348.00g
- Wossner Part Number: 8574D200
- Lock Part Number: CW24
- Pin Part Number: WP023
- Ring Set Part Number: 990XSY
- Rod Part Number: P4028
