PISTON KIT 90-99 DR350 79.00, FORGED WOSSNER 8600DA 12111-14D03-0F0
Wössner 79mm forged piston kit with part number 8600DA. Designed for optimal combustion chamber heat transfer and uniform load distribution. Engineered to reduce localized pressure and prevent piston collapse. Made in Germany. Features forged construction for superior strength and durability, optimized heat transfer to cylinder walls, elliptical design for uniform bearing surface under heat expansion, and even distribution of thrust loads. Specifications include a bore size of 79.00mm, lock part number CW20, pin part number WP038, ring set part number 790XDS, displacement of 349 cm³, stroke of 71.20mm, clearance of 0.06mm, compression ratio of OEM 9.50:1, dome volume of +3.50 cm³, and compression height of 25.00mm. Cross-reference OEM part numbers: 12111-14D03-0F0, 4576M07900. Weight is 364 grams.
- SKU
- 56-W4576.A.WO
- Brand
- Wossner
- Availability
- Out of Stock
FULL DESCRIPTION
Wossner 79mm Forged Piston Kit for Suzuki DR350
Upgrade your Suzuki DR350's performance and durability with this high-quality 79mm forged piston kit from Wossner. Engineered in Germany, this kit is designed for optimal combustion efficiency and longevity, ensuring your motorcycle performs at its peak.
Key Features:
- Forged Construction: Provides superior strength and durability compared to cast pistons, capable of withstanding higher stresses and temperatures.
- Optimized Heat Transfer: Engineered to efficiently transfer heat to the cylinder walls, promoting consistent operating temperatures and reducing the risk of overheating.
- Elliptical Design: Ensures a uniform bearing surface even under extreme heat expansion, reducing localized pressure points.
- Even Load Distribution: Minimizes localized pressure and evenly distributes thrust loads across the piston skirt, preventing premature wear.
- Piston Collapse Prevention: Designed to maintain its structural integrity under high-stress conditions, preventing piston collapse and potential engine damage.
Specifications:
- Bore Size: 79.00mm
- Wossner Part Number: 8600DA
- Lock Part Number: CW20
- Pin Part Number: WP038
- Ring Set Part Number: 790XDS
- Displacement: 349 cm³
- Stroke: 71.20mm
- Clearance: 0.06mm
- Compression Ratio: OEM (9.50:1)
- Dome Volume: +3.50 cm³
- Compression Height: 25.00mm
Cross-Reference OEM Part Numbers:
- 12111-14D03-0F0
- 4576M07900
