PISTON KIT 92-98 HSV 250 67.00, HUSQVARNA WOSSNER 8015DA
This Wossner forged piston kit features a 67.00mm standard bore and is manufactured in Germany. It has a forged construction for high durability and mechanical reliability, with an elliptical profile that allows for uniform expansion under thermal stress, preventing localized pressure build-up and piston collapse. The design aids in efficient heat dissipation from the combustion chamber to the cylinder wall for consistent performance in two-stroke engines. Specifications include an actual diameter of 66.94mm, a compression height of 35.00mm, a stroke of 70.80mm, and a displacement of 249 cm³. Piston clearance is 0.06mm, and the compression ratio is 2-stroke (Wossner and OEM). This kit includes lock CW18, pin WP033, and two ring sets RSB6700. The Wossner Piston Kit Part No is 8015DA, with a cross-reference of 6700M06700.
- SKU
- 56-W699.A.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit 67.00mm for Husqvarna CR250/WR250 (1992-1998)
Enhance the performance and reliability of your Husqvarna CR250 or WR250 with this Wossner forged piston kit. Engineered in Germany, this premium piston kit is designed for the specific demands of two-stroke engines, offering superior durability and optimal heat management.
The piston features an innovative elliptical profile that allows for uniform expansion under the high temperatures of operation. This intelligent design prevents localized pressure points and the risk of piston collapse, ensuring consistent performance and extending the life of your engine components.
Crafted from high-strength forged aluminum, this piston is built for exceptional mechanical reliability. Its construction promotes efficient heat dissipation from the combustion chamber directly to the cylinder wall, crucial for maintaining peak performance during demanding rides. Experience German precision engineering and a commitment to quality with this essential engine upgrade.
Key Features:
- High Durability: Forged construction provides superior strength and resilience.
- Advanced Thermal Management: Elliptical shape ensures even expansion and prevents stress build-up.
- Reduced Risk of Failure: Minimizes localized pressure points for greater engine reliability.
- Optimized Heat Transfer: Enhances cooling from the combustion chamber to the cylinder wall.
- Precision Manufacturing: Made in Germany to exacting standards.
Specifications:
- Standard Bore Size: 67.00mm
- Actual Piston Diameter: 66.94mm
- Compression Height: 35.00mm
- Stroke: 70.80mm
- Displacement: 249 cm³
- Recommended Piston Clearance: 0.06mm
- Compression Ratio: Compatible with Wossner and OEM specifications for 2-stroke engines.
Included Components:
- Wossner Piston Kit Part Number: 8015DA
- Lock Clip: CW18
- Piston Pin: WP033
- Ring Set: RSB6700 (x2)
Cross-Reference Part Numbers:
- 699M06700
