PISTON KIT 98-01 YFM600 100.00, FORGED WOSSNER 8501D500
Wossner 100.00mm forged piston kit is designed for strength and durability, engineered for optimal heat transfer and efficient cooling of the combustion chamber. The elliptical design provides a uniform bearing surface, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany for precision and reliability. Features include forged construction for enhanced strength and longevity, optimized heat transfer for improved engine performance, and an elliptical design that prevents piston collapse and ensures even load distribution. Specifications: Bore Size: 100.00mm, Actual Bore Diameter: 99.93mm, Displacement: 595 cm³, Stroke: 84.00mm, Clearance: 0.07mm, Wossner Compression Ratio: 10.70:1, OEM Compression Ratio: 8.50:1, Dome Volume: -0.50 cm³, Compression Height: 28.00mm, Lock Part Number: CW22, Pin Part Number: WP017, Ring Set Part Number: 1000XSY.
- SKU
- 56-W4797+500.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner 100.00mm Forged Piston Kit
This Wossner 100.00mm forged piston kit is engineered for superior strength and durability. Designed for optimal heat transfer, it ensures efficient cooling within the combustion chamber, contributing to enhanced engine performance. The piston features an elliptical design that creates a uniform bearing surface, effectively reducing localized pressure and distributing thrust loads evenly. This design prevents piston collapse and maintains consistent performance.
Key Features:
- Forged construction for maximum strength and longevity.
- Optimized heat transfer for improved engine cooling and performance.
- Elliptical design to prevent piston collapse and ensure even load distribution.
- Precision manufactured in Germany to exacting quality standards.
Specifications:
- Bore Size: 100.00mm
- Actual Bore Diameter: 99.93mm
- Displacement: 595 cm³
- Stroke: 84.00mm
- Clearance: 0.07mm
- Wossner Compression Ratio: 10.70:1
- OEM Compression Ratio: 8.50:1
- Dome Volume: -0.50 cm³
- Compression Height: 28.00mm
- Lock Part Number: CW22
- Pin Part Number: WP017
- Ring Set Part Number: 1000XSY
