PISTON KIT SET/4 CBR954RR, WOSSNER K8804DA-4 75.00mm
Wossner forged piston kit K8804DA-4, standard 75.00mm bore set. Built to meet OEM compression standards, this kit combines precision engineering with superior material strength for high-performance applications. Manufactured in Germany, this four-piston kit ensures effective thermal management and durability. Features include forged construction, optimal combustion chamber heat dissipation, and an elliptical piston profile to promote even expansion and reduce the risk of localized pressure and piston collapse. Specifications: Bore 75.00mm (STD), Piston code Wossner K8804DA-4, Clip part number CW17, Piston pin WP083, Displacement 954 cm³, Stroke 54.00 mm, Clearance 0.06 mm, Wossner compression ratio OEM, OEM compression ratio 11.50:1, Dome volume -3.10 cm³, Compression height 23.50 mm, Theoretical weight 186.00 g.
- SKU
- 56-W9883.00A.WO
- Brand
- Wossner
- Availability
- In Stock (1)
FULL DESCRIPTION
Wossner Forged Piston Kit for Honda CBR954RR
Enhance your motorcycle's performance and durability with this Wossner forged piston kit. Designed for precision and strength, this kit is engineered to meet OEM compression standards, making it ideal for high-performance applications and demanding engine conditions.
Key Features
- Forged construction for maximum strength and reliability.
- Engineered for optimal combustion chamber heat dissipation.
- Elliptical piston profile promotes even expansion and thrust load distribution.
- Reduces the risk of localized pressure and piston collapse.
- Manufactured in Germany to exacting standards.
Specifications
- Bore: 75.00mm (STD)
- Piston Code: Wossner K8804DA-4
- Clip Part Number: CW17
- Piston Pin: WP083
- Displacement: 954 cm³
- Stroke: 54.00 mm
- Clearance: 0.06 mm
- Wossner Compression Ratio: OEM
- OEM Compression Ratio: 11.50:1
- Dome Volume: -3.10 cm³
- Compression Height: 23.50 mm
- Theoretical Weight: 186.00 g
